| ModelNote） | Specifications | Accessory | ||||
| Minimum supply pressure (Mpa) | Set pressure(MPa) | Connection | Pressure gauge | Bracket | ||
| Basic type | NIR1000-01 | Set pressure + 0.5 | 0.005-0.2 | 1/8 | G33-2-01 | P36201023 |
| NIR1010-01 | 0.01-0.4 | G33-4-01 | ||||
| NIR1020-01 | 0.01-0.8 | G33-10-01 | ||||
| NIR2000-02 | 0.005-0.2 | 1/4 | G43-2-01 | P36202028 | ||
| NIR2010-02 | 0.01-0.4 | G43-4-01 | ||||
| NIR2020-02 | 0.01 ~0.8 | G43-10-01 | ||||
| NIR3000-口 | Set pressure + 0.1 | 0.01-0.2 | 1/4 , 3/8 , 1/2 | G43-2-01 | P362030-20 | |
| NIR3010-口 | 0.01-0.4 | G43-4-01 | ||||
| NIR3020-口 | 0.01-0.8 | G43-10-01 | ||||
| Air operated typ | NIR2120-02 | Set pressure + 0.05 | 0.01-0.8 | 1/4 | P36202028 | |
| NIR3120-口 | Set pressure + 0.1 | 0.01-0.8 | 1/4,3/8,1/2 | P362030-20 | ||
| Sensitivity | Within 0.2% of full span | ||
| Repeatability | Within ±0.5% of full span | ||
| Air consumption | NIR10口0 | 4.4 L/min (ANR) or less | |
| NIR20口0 NIR2120 | 4.4 L/min (ANR) or less | ||
| NIR30口0 NIR3120 | 11.5 L/min (ANR) or less | ||
| Ambient and fluid temperature | -5℃~60℃（(No freezing） | ||
| Supply pressure | 1.0MPa | ||
| Pressure gauge port | Rc1/8 | ||
