The main function of the air claw is to replace the grab work, can effectively improve the production efficiency and work safety. The air claw is connected with a transmission mechanism on the cylinder piston rod to drive the claw finger to translate in a straight line or open and close around a fulcrum to clamp or release the workpiece. So what are the types of air claw? Together with Xiaobian to understand it!

1. Swing the air claw

There is a ring groove on the piston rod of the swinging claw. Because the finger trunnion is connected with the ring groove, the finger can move at the same time and automatically align, and ensure that the grabbing torque is constant.

2. Rotate the air claw

The action of rotating jaw is based on the meshing principle of the rack. The piston is attached to a shaft that moves up and down. The wrong end of the shaft has three ring grooves which engage with the two driving wheels. Therefore, pneumatic fingers can move at the same time and automatically align, and the pinion and rack principle ensures that the grasping force is always constant.

3. Parallel air claw

The parallel air claw is operated by two pistons. Each piston is connected to the pneumatic finger by a roller and a double crank to form a special driving unit. In this way, the pneumatic fingers always move axially to the center, and each finger cannot move separately. If the finger moves in reverse, the previously pressurized piston is vented and the other piston is pressurized.

The above is the introduction of the types of air claw, as follows to learn more product categories, online consultation customer service, you can also call to consult our company's technical personnel, we will be dedicated to provide you with quality service!
